>> Product Introduction
The polyester monofilament/polyester multifilament double-layer self-winding tube is an innovative flexible pipe designed for high-strength and wear-resistant scenarios. It uses polyester materials and elastic structure composite technology, and has the characteristics of lightweight, tensile resistance, chemical corrosion resistance and self-winding recovery. The inner layer of polyester monofilament provides a smooth fluid channel, and the outer layer of polyester multifilament braiding enhances the compression and impact resistance. It is suitable for industrial automation, automobile manufacturing, environmental protection equipment and high-end equipment, and meets the reliability and durability requirements under complex working conditions.
>> Product Advantage
Product Name: Orange doube-layer warning self rolling pipe
Material: polyester monofilanent, polyester multifilament
Working temperature: -50℃+150°C
Melting point: 240 ± 10℃
Flame retardant grade: UL94 neets grade V-1
Wear resistance: ≥grade 8
Color: Black + Orange
Usage: the products are widelused in wires, cables, flat harnessautomobiles,automation:s and hoses of high-speed railways equipment and instruments,specially in the field ofirregular harnesses
Cutting tool: hot knife
Certification: RoHS, halogen-ree certification
>> Technical Parameters
Inner diameter (mm) | Expanded Width (mm) | Standard packaging (M/R) |
φ8 | 45±3 | 100 |
φ10 | 55±4 | 100 |
φ13 | 75±5 | 100 |
φ16 | 85±5 | 50 |
φ19 | 90±5 | 25 |
φ25 | 115±5 | 25 |
φ29 | 125±8 | 25 |
>> FAQ
Q: Why choose us?
We have more than 15 years of experience in this industry;
OEM & ODM;
Ready-made products will be shipped within three days, and customized products will be shipped within 15 days;
Q: Do you have any certificate?
We have pass ISO16949, ISO14001, REACH, RoHS2.0, CE, EN45545 Test Report, ELV Test report
Q: What's the MOQ for your production?
We accept both large and small order, please contact us for details.
Q: Can i expect to get the sample?
Sure, Free samples can sent to you for test.
